Model Name : Vertical Double Chamber Vacuum Packing Machine.
Chamber Size : Width 820mm X Depth/Length 150mm X Height 620mm.
Overall Size : 1860mm x 1110mm x 1700mm including castor wheels.
Gross weight : 700kg, Net weight with pump approx.: 455kg.
Power : Maximum 3500watts.
Construction : Complete SS 304.
Vacuum Pump (Busch - Made in Germany) : 1050 LPM/ 63 cum³/ hr, single stage for faster vacuum. Oil re-circulating hence requires less oil, low noise (< 75 db), no emission of oil mist.
Lid : SS 304 with1ss dome is there and no glass window is provided.
Sealing bar size : Four sealing bar 800mm each
Packing cycle : Vacuum 30 +sealing 3 + Cooling 5. Total: 38 Seconds
Gas purging facility : By default
We make customize machines as per customers requirement, quantity no bar.
Model Name : Vertical model for Liquids / Pastes.
Vacuum chamber size : 550 Width x 120 Length x 700 mm Height.
Construction : Complete SS 304.
Lid : SS 304.
Gas : By default.
Vacuum pump : 20 / 40 cum.
Vacuum monitoring & control : German dial gauge, dial gauge & vacuum sensor optional.
Electrical consumption : Maximum 2.00 KW can be connected to domestic 15 amp domestic supply.
Packing cycle : 2 to 3 Cycles/ minute depending upon the product to vacuum packed.
Pouch hanging arrangement : SS hooks
Winner special : Maintenance free Vacuum actuator for lifting sealing bars. Does not require compressor.
Fiber glass sealing bars for short circuit protection.
We make customize machines as per customers requirement, quantity no bar.
